8.4 – 12.5 GHz, Linear to Circular Polarizer

282X-XX/.XXX/90, Bandwidth 2 GHz, Insertion Loss 1.0 dB


Mi-Wave’s 282 Series linear to circular polarizers converts input linear signals to circularly polarized output signals. The circular polarization sense (RHCP or LHCP) and center frequency should be specified at the time of order. This linear to circular polarized for antennas will yield a maximum VSWR of 1.2 an axial ratio of 1.0 dB maximum over the indicated bandwidth.

Higher frequencies available upon request.


• VSWR < 1.2

• Axial Ratio < 1.0 dB Over the indicated bandwidth.

• Converts Linear Input Signals to Circular Out

• Specify Sense of Circular RF Polarization (RHCP or LHCP)

• Available from 12.4 to 220 GHz with 3% or Greater Bandwidth.


• SatComm

• Test & Measurement Labs

• RF Communication

*All data presented is collected from a sample lot.
* Actual data may vary unit to unit, slightly.
*All testing was performed under +25 °C case temperature.
*Consult factory to confirm if material, plating, size, shape, orientation and any electrical parameter is critical for the application as website information is for reference only.
*Millimeter Wave Products, Inc. reserves the right to change the information presented on website without notice as we continue to enhance the performance and design of our products.

Linear to Circular Polarizers

Millimeter Wave Products Inc. offers linear to circular polarizers in the frequency range of 12 GHz to 220 GHz.

Custom designs available for our RF polarizers. Please consult with our staff for this and any other antenna product needs.
