Q-Band | RF Terminations | 33GHz – 50GHz | Medium Power

Q-Band, 33 – 50 GHz, BroadBand Medium Power Terminations 581B/383, Power Handling 5.0W, VSWR 1.10:1 Description Mi-Wave’s 581 Series Terminations are designed with standard waveguide flanges for use from 8.2 to 220 GHz. Each unit consists of a short length of waveguide and an integral matched terminal load. Individual resistive dielectric loads are tapered to precise wedge configurations for maximum effective energy absorption. The gradual taper provides a low VSWR over the full

Brian Lapuste2021-08-09T19:58:05-04:00

Ka-Band | RF Terminations | 26.5GHz – 40GHz | Medium Power

Ka-Band, 26.5 – 40 GHz, BroadBand Medium Power Terminations 581A/599, Power Handling 7.0W, VSWR 1.10 Description Mi-Wave’s 581 Series Terminations are designed with standard waveguide flanges for use from 8.2 to 220 GHz. Each unit consists of a short length of waveguide and an integral matched terminal load. Individual resistive dielectric loads are tapered to precise wedge configurations for maximum effective energy absorption. The gradual taper provides a low VSWR over the full

Brian Lapuste2021-08-09T19:58:28-04:00

High Power Terminations | Loads

High Power Load Terminations Mi-Wave’s 582 Series Terminations are designed with standard waveguide flanges for use from 12.4 to 220 GHz. Each unit consists of a short length of the waveguide and an integral matched terminal load. Individual resistive dielectric loads are tapered to precise wedge configurations for maximum effective energy absorption. The gradual taper provides a low VSWR over the full waveguide bandwidth. Note: Power requirements for the 582 Series is up to 250 Watts CW, please

Brian Lapuste2025-01-06T12:11:52-05:00

Medium Power Terminations | Loads | Broadband | 8.2GHz – 260GHz

Medium Power Terminations Mi-Wave’s 581 Series Terminations are designed with standard waveguide flanges for use from 12.4 to 220 GHz. Each unit consists of a short length of waveguide and an integral matched terminal load. Individual resistive dielectric loads are tapered to precise wedge configurations for maximum effective energy absorption. The gradual taper provides a low VSWR over the full waveguide bandwidth. The 581 Series Terminations are used in experimental and developmental test sets where a low

Brian Lapuste2023-09-26T16:56:55-04:00

W-Band | RF Low Power Terminations | loads | 75GHz-110GHz

W-Band, 75 – 110 GHz, BroadBand Low Power Terminations 580W/387, Power Handling 0.4W, VSWR 1.06:1 Description Mi-Wave’s 580 Series Terminations are designed with standard waveguide flanges for use from 5 to 320 GHz. Each unit consists of a short length of waveguide and an integral matched terminal load. Individual resistive dielectric loads are tapered to precise wedge configurations for maximum effective energy absorption. The gradual taper provides a low VSWR over the full

Brian Lapuste2023-04-07T19:12:29-04:00

V-Band | RF Low Power Terminations | loads | 50GHz-75GHz

V-Band, 50 – 75 GHz, BroadBand Low Power Terminations 580V/385, Power Handling 1.0W, VSWR 1.06:1 Description Mi-Wave’s 580 Series Terminations are designed with standard waveguide flanges for use from 5 to 320 GHz. Each unit consists of a short length of waveguide and an integral matched terminal load. Individual resistive dielectric loads are tapered to precise wedge configurations for maximum effective energy absorption. The gradual taper provides a low VSWR over the full

Brian Lapuste2023-03-29T15:20:04-04:00

U-Band | RF Low Power Terminations | loads | 40GHz-60GHz

U-Band, 40 – 60 GHz, BroadBand Low Power Terminations 580U/383, Power Handling 2W, VSWR 1.06:1 Description Mi-Wave’s 580 Series Terminations are designed with standard waveguide flanges for use from 5 to 320 GHz. Each unit consists of a short length of waveguide and an integral matched terminal load. Individual resistive dielectric loads are tapered to precise wedge configurations for maximum effective energy absorption. The gradual taper provides a low VSWR over the full

Brian Lapuste2023-04-07T19:18:46-04:00

K-Band | RF Low Power Terminations | loads | 18GHz-26.5GHz

K-Band, 18 – 26.5 GHz, BroadBand Low Power Terminations 580K/595, Power Handling 6W, VSWR 1.05:1 Description Mi-Wave’s 580 Series Terminations are designed with standard waveguide flanges for use from 5 to 320 GHz. Each unit consists of a short length of waveguide and an integral matched terminal load. Individual resistive dielectric loads are tapered to precise wedge configurations for maximum effective energy absorption. The gradual taper provides a low VSWR over the full

Brian Lapuste2021-08-09T20:02:59-04:00

H-Band | RF Low Power Terminations | loads | 170GHz-260GHz

H-Band, 170 – 260 GHz, BroadBand Low Power Terminations 580D/387, Power Handling 0.1W, VSWR 1.10 Description Mi-Wave’s 580 Series Terminations are designed with standard waveguide flanges for use from 5 to 320 GHz. Each unit consists of a short length of waveguide and an integral matched terminal load. Individual resistive dielectric loads are tapered to precise wedge configurations for maximum effective energy absorption. The gradual taper provides a low VSWR over the full

Brian Lapuste2021-08-09T20:03:31-04:00
